Type IVG (with metal internal thread.)

IVG hose threads are made of specially modified polyamide 6, thermoplastic elastomer, and nickel-plated brass. These materials are free of halogens, phosphorus, and cadmium.

IVG hose threaded connections have the following advantages:

  • Quick installation: insert the hose, screw the top on and you're done.
  • No missing parts, condition upon delivery corresponds to condition upon installation
  • Vibration-resistant thanks to the snap-on union nut
  • Full circumference clamping of the hose ensures maximum tensile strength
  • High level of tightness IP 68/69K up to 6 bar without additional attachments according to DIN IEC 60529

Specification:

  • EN 45545-2 3x HL3
  • NFPA 130: ASTM E 162, ASTM E 662
SKU: 183345 Category:

Description

Options

Name GTIN Article
IVG M12-M: Black 4045005165794 83571052
IVG M16-M: Black 4045005170316 83571054
IVG M20-M: Black 4045005095213 83571056
IVG M25-M: Black 4045005300607 83571058
IVG M32-M: Black 4045005106070 83571060
IVG M40-M: Black 4045005083449 83571062
IVG M50-M: Black 4045005077165 83571064



Additional details

Type of product Order number Color UV Connecting thread Suitable for Murrflex EH mm GL mm LW mm SW 1/2 mm Qty. pcs.

IVG M12-M

83571052

Black

1

M12 x 1.5

M12/P09

31

8

6.5

19/20

50

IVG M16-M

83571054

Black

1

M16 x 1.5

M16/P11

37

8

10

22/25

50

IVG M20-M

83571056

Black

1

M20 x 1.5

M20/P16

45

10

14

27/33

50

IVG M25-M

83571058

Black

1

M25 x 1.5

M25/P21

47

10

18.3

33/41

50

IVG M32-M

83571060

Black

1

M32 x 1.5

M32/P29

56

13

24

43/50

25

IVG M40-M

83571062

Black

1

M40 x 1.5

M40/P36

70

14

33

54/60

25

IVG M50-M

83571064

Black

1

M50 x 1.5

M50/P48

80

15

44

67/75

10
