P-VW 90-M

P-VW 90-M

The M-PRO P-VW 90°-M hose coupling, a super-tight and cable-safe threaded coupling with a 90° metal male thread, is used for quick and secure connections of corrugated pipes. It offers excellent chemical resistance and is suitable for outdoor use thanks to its UV and weather resistance.

Specification:

  • ECE 324 R 118 Annex 6+8

Other benefits:

  • Installation/dismantling of corrugated pipes without tools
  • High density padding
  • High degree of fixation
  • Resistance to vibration, shock and vibration



SKU: 185141 Category:

Description

Options

Name GTIN Article
P-VW/L 90-M12/09-M: Black 4045005430298 83405254
P-VW/L 90-M16/11-M: Black 4045005446015 83405258
P-VW/L 90-M20/16-M: Black 4045005445964 83405263
P-VW/L 90-M25/21-M: Black 4045005445919 83405268
P-VW/L 90-M32/29-M: Black 4045005445872 83405272
P-VW/L 90-M40/36-M: Black 4045005445834 83405276
P-VW/L 90-M50/48-M: Black 4045005445797 83405280
P-VW/L 90-PG09/09-M: Black 4045005430021 83405653
P-VW/L 90-PG16/16-M: Black 4045005429988 83405663
P-VW/L 90-PG21/21-M: Black 4045005429971 83405666
P-VW/L 90-PG29/29-M: Black 4045005429964 83405668
P-VW/L 90-PG36/36-M: Black 4045005429957 83405670
P-VW/L 90-PG48/48-M: Black 4045005429940 83405672



Metric metal thread

Type of product Color GTIN Quantity Min. order
P-VW/L 90-M12/09-M Black 4045005430298 4 8
P-VW/L 90-M16/11-M Black 4045005446015 4 8
P-VW/L 90-M20/16-M Black 4045005445964 4 8
P-VW/L 90-M25/21-M Black 4045005445919 4 8
P-VW/L 90-M32/29-M Black 4045005445872 2 4
P-VW/L 90-M40/36-M Black 4045005445834 2 4
P-VW/L 90-M50/48-M Black 4045005445797 2 4



Metal thread type PG

Type of product Color GTIN Quantity Min. order
P-VW/L 90-PG09/09-M Black 4045005430021 4 8
P-VW/L 90-PG16/16-M Black 4045005429988 4 8
P-VW/L 90-PG21/21-M Black 4045005429971 4 8
P-VW/L 90-PG29/29-M Black 4045005429964 2 4
P-VW/L 90-PG36/36-M Black 4045005429957 2 4
P-VW/L 90-PG48/48-M Black 4045005429940 2 4

Additional details

Type of product Order number Color UV Connecting thread Suitable for Murrflex A mm EH mm AD mm GL mm LW mm B mm SW mm Qty. pcs.
Metric metal thread

P-VW/L 90-M12/09-M

83405254

Black

1

M12 x 1.5

M12/P09

50.7

39.7

25

12

5.5

63.8

11

4

P-VW/L 90-M16/11-M

83405258

Black

1

M16 x 1.5

M16/P11

52.6

41.6

27.9

12

8.9

66

15

4

P-VW/L 90-M20/16-M

83405263

Black

1

M20 x 1.5

M20/P16

58.1

47.1

33.7

12

12.5

73.8

19

4

P-VW/L 90-M25/16-M

83405265

Black

1

M25 x 1.5

M20/P16

59.1

47.4

33.7

13

17

77

24

4

P-VW/L 90-M25/21-M

83405268

Black

1

M25 x 1.5

M25/P21

66.2

54.4

41.6

13

17

84.1

24

4

P-VW/L 90-M32/29-M

83405272

Black

1

M32 x 1.5

M32/P29

76.4

63.7

51

14

23.2

100.4

30

2

P-VW/L 90-M40/36-M

83405276

Black

1

M40 x 1.5

M40/P36

91

76

59.3

17

29.9

113.7

41

2

P-VW/L 90-M50/48-M

83405280

Black

1

M50 x 1.5

M50/P48

104.3

89.3

71

17

38.8

128.8

50

2
Metal thread type PG

P-VW/L 90-PG09/09-M

83405653

Black

1

PG 09

M12/P09

50.7

39.7

25

12

7.8

63.3

14

4

P-VW/L 90-PG16/16-M

83405663

Black

1

PG 16

M20/P16

59.1

47.1

33.7

13

14.3

77

21

4

P-VW/L 90-PG21/21-M

83405666

Black

1

PG 21

M25/P21

67.2

54.7

41.6

14

19.8

87.8

28

4

P-VW/L 90-PG29/29-M

83405668

Black

1

PG 29

M32/P29

77.4

64.9

51

14

26.5

104.9

34

2

P-VW/L 90-PG36/36-M

83405670

Black

1

PG 36

M40/P36

91

76

59.3

17

36.2

118.7

46

2

P-VW/L 90-PG48/48-M

83405672

Black

1

PG 48

M50/P48

105.3

90.3

71

17

47.1

135.3

60

2
