Type CKW (fitting for hose and cable)

CKW 90° bend and expandable combination threaded fittings for cables and hoses with plastic threads are made of specially modified polyamide and perbunan. These materials are free of halogens, phosphorus, and cadmium.

CKW 90° threaded hose connections have the following advantages:

  • No missing parts, condition upon delivery corresponds to condition upon installation
  • Optimal cable strain relief thanks to thin iris diaphragm blades
  • IP 65 tightness under static and dynamic loads
  • High degree of fixation thanks to the integrated clamping ring
  • Easy installation of cables thanks to the folding corner element

Specification:

  • EN 45545-2 3x HL3
  • NFPA 130: ASTM E 162, ASTM E 662



SKU: 183796 Category:

Description

Options

Name GTIN Article
CKW-M16x1.5/9: Black 4045005031457 83584250
CKW-M20x1.5/16: Black 4045005272935 83584256
CKW-M25x1.5/21: Black 4045005022745 83584258
CKW-M32x1.5/29: Black 4045005072023 83584260
CKW-Pg 09: Black 4045005393432 83581050
CKW-Pg 11: Black 4045005393425 83581052
CKW-Pg 16: Black 4045005241276 83581054
CKW-Pg 21: Black 4045005393418 83581056
CKW-Pg 29: Black 4045005167941 83581058



Additional details

Type of product Order number Color UV Connecting thread Suitable for Murrflex EH mm GL mm Clamping range (LW) mm SW 2/3 mm Qty. pcs.

CKW-M16x1.5/9

83584250

Black

1

M16 x 1.5

M12/P09

23

8

4–8

22/22

50

CKW-M20x1.5/16

83584256

Black

1

M20 x 1.5

M20/P16

32

9

6–12

27/27

50

CKW-M25x1.5/21

83584258

Black

1

M25 x 1.5

M25/P21

40

12

13–18

33/33

10

CKW-M32x1.5/29

83584260

Black

1

M32 x 1.5

M32/P29

50

12

18–25

42/42

25

CKW-Pg 09

83581050

Black

1

PG 09

M12/P09

23

8

4–8

19/19

50

CKW-Pg 11

83581052

Black

1

PG 11

M16/P11

28

8

5–10

22/22

50

CKW-Pg 16

83581054

Black

1

PG 16

M20/P16

37

11

10–14

27/27

50

CKW-Pg 21

83581056

Black

1

PG 21

M25/P21

39

11

13–18

33/33

25

CKW-Pg 29

83581058

Black

1

PG 29

M32/P29

50

11

18–25

42/42

25
