Type AT

AT couplings are fastenings for detachable and closed hoses of the EW and EWT series.

They are made from specially modified polyamide 6. This material is self-extinguishing and does not contain halogens, phosphorus or cadmium.

AT connections have the following advantages:

Quick and easy assembly and disassembly without tools thanks to the snap-on system
Compact design
The hoses remain rotating
Suitable for separate and closed hoses

Description

Additional details

Type of product	Order number	Color	UV	Suitable for Murrflex	A mm	B mm	C mm	D mm	E mm	F mm	Qty. pcs.

AT M20/P09	83651050	Black	1	M12/P09	20.2	35	16	9.5	5	20.5	50
AT M25/P11	83651052	Black	1	M16/P11	25.2	40.5	16	9.5	5	25.5	50
AT M32/P16	83651054	Black	1	M20/P16	32.2	48	17.2	10.3	5.4	32.5	50
AT M40/P21	83651056	Black	1	M25/P21	40.2	58	17.9	10	6.4	40.5	50
AT M50/P29	83651058	Black	1	M32/P29	50.2	68	17.9	10	6.4	50.5	25
AT M50/P36	83651060	Black	1	M40/P36	50.2	68	21.5	12	8	50.5	10
AT M63/P48	83651062	Black	1	M50/P48	63.2	82	24.8	15.3	8	63.5	10
AT M20/P09	83651010	Grey	0	M12/P09	20.2	35	16	9.5	5	20.5	50
AT M25/P11	83651012	Grey	0	M16/P11	25.2	40.5	16	9.5	5	25.5	50
AT M32/P16	83651014	Grey	0	M20/P16	32.2	48	17.2	10.3	5.4	32.5	50
AT M40/P21	83651016	Grey	0	M25/P21	40.2	58	17.9	10	6.4	40.5	50
AT M50/P29	83651018	Grey	0	M32/P29	50.2	68	17.9	10	6.4	50.5	25
AT M50/P36	83651020	Grey	0	M40/P36	50.2	68	21.5	12	8	50.5	10
AT M63/P48	83651022	Grey	0	M50/P48	63.2	82	24.8	15.3	8	63.5	10
