Type EWX-PAE-LS (high corrugation)

EWX-PAE-LS cable protection conduits are made from a specially modified polyamide 12. This material is free of halogens, phosphorus, and cadmium.

Thanks to their excellent fatigue resistance, these products are suitable for use in robotics and material handling systems. They are also suitable for installing pre-assembled wires, additional installations, or repairs to wiring. They are also suitable for dynamic applications under low to moderate mechanical loads.

EWX-PAE-LS cable protection conduits feature increased corrugation and provide the following benefits:

  • Very high flexibility
  • Excellent bending fatigue strength
  • Reduced wear
  • Good compression resistance
  • possibility of additional installation.



SKU: 182481 Categories: ,

Description

Options

Name GTIN Article
EWX-PAE-LS M20/P16: Black 4045005309648 83182256
EWX-PAE-LS M25/P21: Black 4045005304551 83182258
EWX-PAE-LS M32/P29: Black 4045005190666 83182260
EWX-PAE-LS M40/P36: Black 4045005305596 83182262
EWX-PAE-LS M50/P48: Black 4045005061133 83182264
EWX-PAE-LS 56 Jumbo: Black 4045005194626 83182278
EWX-PAE-LS 70 Jumbo: Black 4045005186645 83182280



Additional details

Type of product Order number Color UV A Ø mm B Ø mm Static radius mm Dynamic radius mm Weight kg/100 m Qty. m

EWX-PAE-LS M20/P16

83182256

Black

1

13.3

21.1

36

77

6.0

50

EWX-PAE-LS M25/P21

83182258

Black

1

19.2

28.2

49

104

11.0

50

EWX-PAE-LS M32/P29

83182260

Black

1

23.1

34.5

57

117

14.0

25

EWX-PAE-LS M40/P36

83182262

Black

1

28.5

42.2

71

146

18.2

25

EWX-PAE-LS M50/P48

83182264

Black

1

36.5

53.6

87

167

24.0

25

EWX-PAE-LS 56 Jumbo

83182278

Black

1

51.7

67.7

95

220

40.0

25

EWX-PAE-LS 70 Jumbo

83182280

Black

1

64.3

80.3

115

235

52.0

25
