Type EWS/F

EWS/F cable protection hoses are made of specially modified polyethylene. This material is free of halogens, phosphorus, and cadmium.

Self-extinguishing EWS/F cable protection conduits are highly flexible, offer excellent bending fatigue resistance, and are available in a special light gray RAL 7035 color. Suitable for very low mechanical loads in mechanical engineering (e.g., for forming cable bundles on switch cabinet doors).

Application area:

  • Manufacturing of distribution cabinets
  • production of industrial installations;
SKU: 182189 Category:

Description

Options

Name GTIN Article
EWS/F-M20/P16S: Light gray 4045005269843 83101814
EWS/F-M25/P21S: Light gray 4045005024756 83101816
EWS/F-M32/P29S: Light gray 4045005194275 83101818
EWS/F-M40/P36S: Light gray 4045005161710 83101820
EWS/F-M50/P48S: Light gray 4045005119933 83101822



Additional details

Type of product Order number Color A Ø mm B Ø mm Static radius mm Weight kg/100 m Qty. m

EWS/F-M20/P16S

83101814

Light gray

16.8

21

55

5.4

25

EWS/F-M25/P21S

83101816

Light gray

22.6

28

65

6.0

25

EWS/F-M32/P29S

83101818

Light gray

29.3

34

75

10.0

25

EWS/F-M40/P36S

83101820

Light gray

36

42.1

85

12.4

25

EWS/F-M50/P48S

83101822

Light gray

47.5

53.3

95

14.5

25
