KMR terminal marking plate

KMR — for terminal block manufacturers Weidmüller, Contact Clip, ABB Entrelec, Clemsan, Schlegel And Wago.

High-quality, halogen-free terminal block plates. Available for individual mounting or in strips.

Large printing surface on
The top section provides the opportunity for individual design and terminal block, eliminating the need for additional device systems.

The nameplate plates designated as "5-6 mm pitch strips" can be adapted to a terminal block width of 5 mm or 6 mm using
flexible connection.

SKU: 177788 Category:

Description

Options

Name GTIN Article
KMR 5/10: White 4045005055651 86401010
KMR 5/15: White 4045005115973 86401014
KMR 6/10: White 4045005187116 86401018
KMR 6/15: White 4045005157164 86401022
KMR 5/10 FA: White 4045005260512 86401032
KMR 3.5/7.5-3.5: White 4045005225078 86401034
KMR 3.5/10-3.5: White 4045005305473 86401046
KMR 5/7.5-5: White 4045005186560 86401026
KMR 5/7.5-5: Yellow 4045005171658 86401036
KMR 5/7.5-5: Red 4045005214393 86401044
KMR 5/7.5-5: Blue 4045005205957 86401040
KMR 5/7.5-5: Orange 4045005389084 86401042
KMR 5/10-5: White 4045005113238 86401012
KMR 5/15-5: White 4045005154187 86401016
KMR 5/15-5: Yellow 4045005336019 86401017
KMR 5/5-5.1: White 4045005020239 86401011
KMR 5/7.5-5.1: White 4045005017628 86401027
KMR 5/7.5-5.1: Yellow 4045005095947 86401037
KMR 5/7.5-5.1: Orange 4045005314420 86401043
KMR 5/10-5.1: White 4045005188137 86401013
KMR 5/15-5.1: White 4045005116949 86401015
KMR 5/10-5.1 FA: White 4045005065377 86401048
KMR 5/10-5…6: White 4045005155900 86401038
KMR 6/10-6: White 4045005305558 86401020
KMR 6/15-6: White 4045005017826 86401024
KMR 6/10-6.1: White 4045005066756 86401021
KMR 6/15-6.1: White 4045005008855 86401025
KMR 6/15-6.7: White 4045005095046 86401028
None 4045005270986 86401031
None 4045005307972 86401033



Individual signs

Type of product Color GTIN Quantity Min. order
KMR 5/10 White 4045005055651 1000 1000
KMR 5/15 White 4045005115973 1000 1000
KMR 6/10 White 4045005187116 1000 1000
KMR 6/15 White 4045005157164 1000 1000



Individual signs, Legs outside (FA)

Type of product Color GTIN Quantity Min. order
KMR 5/10 FA White 4045005260512 1024 1024



Stripes spaced at 3.5mm pitch

Type of product Color GTIN Quantity Min. order
KMR 3.5/7.5-3.5 White 4045005225078 1200 1200
KMR 3.5/10-3.5 White 4045005305473 1200 1200



Stripes spaced at 5mm intervals

Type of product Color GTIN Quantity Min. order
KMR 5/7.5-5 White 4045005186560 1400 1400
KMR 5/7.5-5 Yellow 4045005171658 1400 1400
KMR 5/7.5-5 Red 4045005214393 1400 1400
KMR 5/7.5-5 Blue 4045005205957 1400 42000
KMR 5/7.5-5 Orange 4045005389084 1400 1400
KMR 5/10-5 White 4045005113238 1400 1400
KMR 5/15-5 White 4045005154187 1400 1400
KMR 5/15-5 Yellow 4045005336019 1400 1400



Stripes spaced at 5.1mm pitch

Type of product Color GTIN Quantity Min. order
KMR 5/5-5.1 White 4045005020239 1100 1100
KMR 5/7.5-5.1 White 4045005017628 1008 1008
KMR 5/7.5-5.1 Yellow 4045005095947 1008 1008
KMR 5/7.5-5.1 Orange 4045005314420 1008 1008
KMR 5/10-5.1 White 4045005188137 1008 1008
KMR 5/15-5.1 White 4045005116949 1008 1008
KMR 5/10-5.1 FA White 4045005065377 1008 1008



Stripes spaced at 5-6 mm intervals

Type of product Color GTIN Quantity Min. order
KMR 5/10-5…6 White 4045005155900 1400 1400



Stripes spaced at 6mm intervals

Type of product Color GTIN Quantity Min. order
KMR 6/10-6 White 4045005305558 1000 1000
KMR 6/15-6 White 4045005017826 1000 1000



Stripes spaced at 6.1mm pitch

Type of product Color GTIN Quantity Min. order
KMR 6/10-6.1 White 4045005066756 1008 1008
KMR 6/15-6.1 White 4045005008855 1008 1008



Stripes spaced at 6.7mm pitch

Type of product Color GTIN Quantity Min. order
KMR 6/15-6.7 White 4045005095046 1700 1700

Additional details

Type of product Order number Color RAL similar Marking size * mm Printing surface* mm Quantity per frame Basic panel Software Type of products Qty. pcs.
Individual signs
Individual signs, Legs outside (FA)

KMR 5/10 FA

86401032

White

9016

5×10

5×10

64

GP4
Single tree adapter 4

160

1024
Stripes spaced at 3.5mm pitch

KMR 3.5/7.5-3.5

86401034

White

9016

3.5×7.5

3.5×7.5

120

GP4

161

1200

KMR 3.5/10-3.5

86401046

White

9016

3.5×10

3.5×10

120

GP4

423

1200
Stripes spaced at 5mm intervals

KMR 5/7.5-5

86401026

White

9016

5×7.5

5×7.5

88

GP4

34

1400

KMR 5/7.5-5

86401036

Yellow

1018

5×7.5

5×7.5

88

GP4

34G

1400

KMR 5/7.5-5

86401044

Red

2012

5×7.5

5×7.5

88

GP4

262

1400

KMR 5/7.5-5

86401040

Blue

5012

5×7.5

5×7.5

88

GP4

260

1400

KMR 5/7.5-5

86401042

Orange

2011

5×7.5

5×7.5

88

GP4

261

1400

KMR 5/10-5

86401012

White

9016

5×10

5×10

88

GP4
Single tree adapter 4

35

1400

KMR 5/15-5

86401016

White

9016

5×15

5×15

88

GP4

36

1400

KMR 5/15-5

86401017

Yellow

1018

5×15

5×15

88

GP4

36G

1400
Stripes spaced at 5.1mm pitch

KMR 5/5-5.1

86401011

White

9016

5×5

5×5

100

GP5
Single tree adapter 5

319

1100

KMR 5/7.5-5.1

86401027

White

9016

5×7.5

5×7.5

84

GP4

276

1008

KMR 5/7.5-5.1

86401037

Yellow

1018

5×7.5

5×7.5

84

GP4

286

1008

KMR 5/7.5-5.1

86401043

Orange

2011

5×7.5

5×7.5

84

GP4

296

1008

KMR 5/10-5.1

86401013

White

9016

5×10

5×10

84

GP4
Single tree adapter 4

277

1008

KMR 5/15-5.1

86401015

White

9016

5×15

5×15

84

GP4

278

1008

KMR 5/10-5.1 FA

86401048

White

9016

5×10

5×10

84

GP4
Single tree adapter 4

487

1008
Stripes spaced at 5-6 mm intervals

KMR 5/10-5…6

86401038

White

9016

4×10

4×10

88

GP4
Single tree adapter 4

35U

1400
Stripes spaced at 6mm intervals

KMR 6/10-6

86401020

White

9016

6×10

6×10

72

GP4

37

1000

KMR 6/15-6

86401024

White

9016

6×15

6×15

72

GP4

38

1000
Stripes spaced at 6.1mm pitch

KMR 6/10-6.1

86401021

White

9016

6×10

6×10

72

GP4

37A

1008

KMR 6/15-6.1

86401025

White

9016

6×15

6×15

72

GP4

38A

1008
Stripes spaced at 6.7mm pitch

KMR 6/15-6.7

86401028

White

9016

6×15

6×15

64

GP4

39

1700
