ST-BT-H Для железнодорожного транспорта, с пояском по кромке
ST-BT-H Для железнодорожного транспорта, с пояском по кромке - Image 2

ST-BT-H For railway transport, with a belt along the edge

Polyolefin (PO) heat shrink tubing, type ST-BT-H

Halogen-free, polyolefin, heat-shrinkable cable marker tubing with excellent properties
For use with the thermal pattern transfer method. This hose, with its special approvals, is particularly suitable for applications in air and rail transport, marine and coastal construction, and tunnel construction.

Pre-perforated heat shrink tubing divided into 20mm sections for
Cable identification and a 12 mm section containing information to simplify circuit installation. This section can be discarded after the circuit is installed. This method helps significantly reduce process time.

Characteristics

  • Excellent printing characteristics
  • Flat roll for thermal transfer printing
  • Halogen-free, thin-walled
  • Shrinkage ratio 2:1
  • Vehicle class: 1a according to BS 6853 (1999)
  • Flammability: ASTM D 635-HB
  • Shrinkage temperature: > 90° C
  • Operating temperature: from -55 to +105° C

Standards

  • ASTM D 635-HB "Flammability"«
  • Boeing BSS 7239 "Emission of Toxic Gases During Combustion of Materials" M7
  • Railway standards
  • EN 45545-2 level 3x HL3 (R22)
  • BS6853 (1999) for Class 1a vehicles
  • UNI CEI 11170-3 level LR4
  • DIN 5510-2 Appendix C "Low toxicity of flue gases"«
  • DIN 5510-2 "Droplet Formation Class" ST2
  • DIN 5510-2 "Smoke emission class" SR2
SKU: 240918 Category:

Description

Options

Name GTIN Article
ST-BT-H 20/12-3.2: White 4045005387400 86531100
ST-BT-H 20/12-3.2: Yellow 4045005345424 86532100
ST-BT-H 20/12-4.8: White 4045005396778 86531101
ST-BT-H 20/12-4.8: Yellow 4045005396730 86532101
ST-BT-H 20/12-12.7: White 4045005387394 86531102
ST-BT-H 20/12-12.7: Yellow 4045005345431 86532102
ST-BT-H 20/12-25.4: White 4045005387387 86531103
ST-BT-H 20/12-25.4: Yellow 4045005107343 86532103
ST-BT-H 20/12-3.2: White 4045005387448 86531000
ST-BT-H 20/12-3.2: Yellow 4045005387370 86532000
ST-BT-H 20/12-4.8: White 4045005387431 86531001
ST-BT-H 20/12-4.8: Yellow 4045005387363 86532001
ST-BT-H 20/12-12.7: White 4045005387424 86531002
ST-BT-H 20/12-12.7: Yellow 4045005387356 86532002
ST-BT-H 20/12-25.4: White 4045005387417 86531003
ST-BT-H 20/12-25.4: Yellow 4045005387349 86532003
ST-BT-H 32-3.2: White 4045005396761 86531150
ST-BT-H 32-3.2: Yellow 4045005087751 86532150
ST-BT-H 32-4.8: White 4045005259646 86531151
ST-BT-H 32-4.8: Yellow 4045005161109 86532151
ST-BT-H 32-12.7: White 4045005085207 86531152
ST-BT-H 32-12.7: Yellow 4045005256591 86532152
ST-BT-H 32-25.4: White 4045005140579 86531153
ST-BT-H 32-25.4: Yellow 4045005396723 86532153



For rail transport, with a belt along the edge, marking length 20 mm with an information part for printing 12 mm

Type of product Color GTIN Quantity Min. order
ST-BT-H 20/12-3.2 White 4045005387400 2000 2000
ST-BT-H 20/12-3.2 Yellow 4045005345424 2000 2000
ST-BT-H 20/12-4.8 White 4045005396778 2000 2000
ST-BT-H 20/12-4.8 Yellow 4045005396730 2000 2000
ST-BT-H 20/12-12.7 White 4045005387394 1000 1000
ST-BT-H 20/12-12.7 Yellow 4045005345431 1000 1000
ST-BT-H 20/12-25.4 White 4045005387387 600 600
ST-BT-H 20/12-25.4 Yellow 4045005107343 600 600



For rail transport, with a belt along the edge, marking length 20 mm with an information part for printing 12 mm (Maxirolle)

Type of product Color GTIN Quantity Min. order
ST-BT-H 20/12-3.2 White 4045005387448 20000 19980000
ST-BT-H 20/12-3.2 Yellow 4045005387370 20000 19980000
ST-BT-H 20/12-4.8 White 4045005387431 20000 19980000
ST-BT-H 20/12-4.8 Yellow 4045005387363 20000 19980000
ST-BT-H 20/12-12.7 White 4045005387424 6000 6000
ST-BT-H 20/12-12.7 Yellow 4045005387356 6000 6000
ST-BT-H 20/12-25.4 White 4045005387417 4000 4000
ST-BT-H 20/12-25.4 Yellow 4045005387349 4000 4000



For rail transport, with a belt along the edge, marking length 32 mm

Type of product Color GTIN Quantity Min. order
ST-BT-H 32-3.2 White 4045005396761 2000 2000
ST-BT-H 32-3.2 Yellow 4045005087751 2000 2000
ST-BT-H 32-4.8 White 4045005259646 2000 2000
ST-BT-H 32-4.8 Yellow 4045005161109 2000 2000
ST-BT-H 32-12.7 White 4045005085207 1000 1000
ST-BT-H 32-12.7 Yellow 4045005256591 1000 1000
ST-BT-H 32-25.4 White 4045005140579 600 600
ST-BT-H 32-25.4 Yellow 4045005396723 600 600

Additional details

Type of product Order number Color длина маркировки мм Ширина в плоском виде мм Диаметр кабеля Макс. мм Область усадки от — до Ø мм Recommended color tape Software Type of products Qty. pcs.
For rail transport, with a belt along the edge, marking length 20 mm with an information part for printing 12 mm

ST-BT-H 20/12-3.2

86531100

White

20

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A70

2000

ST-BT-H 20/12-3.2

86532100

Yellow

20

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A74

2000

ST-BT-H 20/12-4.8

86531101

White

20

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A71

2000

ST-BT-H 20/12-4.8

86532101

Yellow

20

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A75

2000

ST-BT-H 20/12-12.7

86531102

White

20

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A72

1000

ST-BT-H 20/12-12.7

86532102

Yellow

20

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A76

1000

ST-BT-H 20/12-25.4

86531103

White

20

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A73

600

ST-BT-H 20/12-25.4

86532103

Yellow

20

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A77

600
For rail transport, with a belt along the edge, marking length 20 mm with an information part for printing 12 mm (Maxirolle)

ST-BT-H 20/12-3.2

86531000

White

20

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A70

20000

ST-BT-H 20/12-3.2

86532000

Yellow

20

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A74

20000

ST-BT-H 20/12-4.8

86531001

White

20

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A71

20000

ST-BT-H 20/12-4.8

86532001

Yellow

20

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A75

20000

ST-BT-H 20/12-12.7

86531002

White

20

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A72

6000

ST-BT-H 20/12-12.7

86532002

Yellow

20

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A76

6000

ST-BT-H 20/12-25.4

86531003

White

20

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A73

4000

ST-BT-H 20/12-25.4

86532003

Yellow

20

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A77

4000
For rail transport, with a belt along the edge, marking length 32 mm

ST-BT-H 32-3.2

86531150

White

32

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A78

2000

ST-BT-H 32-3.2

86532150

Yellow

32

6.2

3.2

3.2–1.6

FB-BT 80mm x 300m

A82

2000

ST-BT-H 32-4.8

86531151

White

32

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A79

2000

ST-BT-H 32-4.8

86532151

Yellow

32

8.5

4.8

4.8–2.4

FB-BT 80mm x 300m

A83

2000

ST-BT-H 32-12.7

86531152

White

32

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A80

1000

ST-BT-H 32-12.7

86532152

Yellow

32

20.9

12.7

12.7–6.4

FB-BT 80mm x 300m

A84

1000

ST-BT-H 32-25.4

86531153

White

32

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A81

600

ST-BT-H 32-25.4

86532153

Yellow

32

40.5

25.4

25.4–12.7

FB-BT 80mm x 300m

A85

600
