KMG/F Ball Joint - SRF Hose Ring

The KMG/F joint and SRF hose ring are used in robots and other mobile manipulators.

The insert, which can be easily and quickly installed in the SH system, is ideal for securing Murrflex cable protection conduits.

The KMG-F swivel and SRF hose ring are made of specially modified polyamide.

Special advantages of the KMG-F central ball joint and SRF hose ring:

Suitable for retrofitting and additional installation
Possibility of use with static fixation (KMG-F + SRF) or axial deflection (KMG-F)
Long service life
Quick and easy installation and dismantling
Providing a secure hold for the Murrflex cable protection hoses

Description

Options

Type of product	Order number	GTIN	Color	Qty. pcs.	Minimum order quantity
Kit composition: SRF + SH 56/70
SRF-68 Kit	83692246	4045005134783	Black	1	1
Central ball joint (fixed) for fastening protective cable hoses
KMG/F-M25	83691658	4045005187857	Black	1	1
KMG/F-M32	83691660	4045005261311	Black	1	1
KMG/F-M40	83691662	4045005188656	Black	1	1
KMG/F-M50	83691664	4045005113870	Black	1	1
Set contents: KMG/F + SH-P M40/M50
KMG-F-M40 Kit	83691663	4045005065308	Black	1	1
KMG-F-M50 Kit	83691665	4045005131614	Black	1	1
Hose ring (fixed) for fastening protective hoses for cables
SRF-M40/P36	83692288	4045005188663	Black	1	1
SRF-M50/P48	83692289	4045005304919	Black	1	1
SRF-56	83692290	4045005154293	Black	1	1
SRF-68	83692291	4045005019615	Black	1	1
SRF-70	83692292	4045005023513	Black	1	1
SRF-80	83692294	4045005286833	Black	1	1
SRF-95	83692296	4045005223524	Black	1	1

Type of product	Order number	Color	A mm	B mm	Suitable for Fastening Device System	Execution	Suitable for Murrflex	Qty. pcs.
Central ball joint (fixed) for fastening protective cable hoses
KMG/F-M25	83691658	Black	42.5	27.5	SH-P / M25-M32	Sectional	M25/P21	1
KMG/F-M32	83691660	Black	42.5	27.5	SH-P / M25-M32	Sectional	M32/P29	1
KMG/F-M40	83691662	Black	69	44	SH M40-M50	Sectional	M40/P36	1
KMG/F-M50	83691664	Black	69	44	SH M40-M50	Sectional	M50/P48	1
Set contents: KMG/F + SH-P M40/M50
KMG-F-M40 Kit	83691663	Black	69	44	—	Sectional	M40/P36	1
KMG-F-M50 Kit	83691665	Black	69	44	—	Sectional	M50/P48	1
Hose ring (fixed) for fastening protective hoses for cables
SRF-M40/P36	83692288	Black	89.5	27	SH 56/70	Sectional	M40/P36	1
SRF-M50/P48	83692289	Black	89.5	27	SH 56/70	Sectional	M50/P48	1
SRF-56	83692290	Black	89.5	27	SH 56/70	Sectional	NW56	1
SRF-68	83692291	Black	89.5	27	SH 56/70	Sectional	NW68	1
SRF-70	83692292	Black	89.5	27	SH 56/70	Sectional	NW70	1
SRF-80	83692294	Black	119	46	SH 80/95	Sectional	NW80	1
SRF-95	83692296	Black	119	46	SH 80/95	Sectional	NW95	1
Kit composition: SRF + SH 56/70
SRF-68 Kit	83692246	Black	89.5	27	—	Sectional	NW68	1
