Панель с кабельными вводами тип KDP/Z FDA
Панель с кабельными вводами тип KDP/Z FDA - Image 2
Панель с кабельными вводами тип KDP/Z FDA - Image 3

Cable entry panel type KDP/Z FDA

Flat plate with plastic cable entries with 2-component design and excellent performance

  • Significant time savings during installation
  • High density padding
  • Wide range of wire diameters
  • Specially designed for use in the food and pharmaceutical sectors
  • Protection class: IP 67
  • Temperature resistance: -30 °C to +70 °C
  • Material: Frame: Polypropylene (PP) / Seal: TPE
  • RoHS compliant
  • UV resistant
  • Made in Germany
  • Fits standard 24-, 16- and 10-pole industrial connector cutouts
  • Can be mounted using clamps or M5 screws



SKU: 210846 Category:

Description

Options

Name GTIN Article
KDP/Z 10/14-FDA, WS/BL, VE 5: White/Blue 4045005366238 87303282
KDP/Z 10/15-FDA, WS/BL, VE 5: White/Blue 4045005285911 87303284
KDP/Z 16/10-FDA, WS/BL, VE 5: White/Blue 4045005007490 87303254
KDP/Z 16/12-FDA, WS/BL, VE 5: White/Blue 4045005367815 87303256
KDP/Z 16/17-FDA, WS/BL, VE 5: White/Blue 4045005364500 87303258
KDP/Z 16/24-FDA, WS/BL, VE 5: White/Blue 4045005166845 87303260
KDP/Z 16/40-FDA, WS/BL, VE 5: White/Blue 4045005425478 87303262
KDP/Z 24/3-FDA: White/Blue 4045005241009 87303202
KDP/Z 24/14-FDA, WS/BL, VE 5: White/Blue 4045005067746 87303210
KDP/Z 24/14-1-FDA, WS/BL, VE 5: White/Blue 4045005164766 87303220
KDP/Z 24/23-FDA, WS/BL, VE 5: White/Blue 4045005231710 87303230
KDP/Z 24/30-FDA, WS/BL, VE 5: White/Blue 4045005155672 87303240
KDP/Z 24/48-FDA, WS/BL, VE 5: White/Blue 4045005415264 87303250



Cable entry panel, type KDP/Z 10

Type of product Color GTIN Quantity Min. order
KDP/Z 10/14-FDA, WS/BL, VE 5 White / blue 4045005366238 5 5
KDP/Z 10/15-FDA, WS/BL, VE 5 White / blue 4045005285911 5 5



Cable entry panel, type KDP/Z 16

Type of product Color GTIN Quantity Min. order
KDP/Z 16/10-FDA, WS/BL, VE 5 White / blue 4045005007490 5 5
KDP/Z 16/12-FDA, WS/BL, VE 5 White / blue 4045005367815 5 5
KDP/Z 16/17-FDA, WS/BL, VE 5 White / blue 4045005364500 5 5
KDP/Z 16/24-FDA, WS/BL, VE 5 White / blue 4045005166845 5 5
KDP/Z 16/40-FDA, WS/BL, VE 5 White / blue 4045005425478 5 5



Cable entry panel, type KDP/Z 24

Type of product Color GTIN Quantity Min. order
KDP/Z 24/3-FDA White / blue 4045005241009 5 5
KDP/Z 24/14-FDA, WS/BL, VE 5 White / blue 4045005067746 5 5
KDP/Z 24/14-1-FDA, WS/BL, VE 5 White / blue 4045005164766 5 5
KDP/Z 24/23-FDA, WS/BL, VE 5 White / blue 4045005231710 5 5
KDP/Z 24/30-FDA, WS/BL, VE 5 White / blue 4045005155672 5 5
KDP/Z 24/48-FDA, WS/BL, VE 5 White / blue 4045005415264 5 5
