Cable entry panel type KDP 24-Multi
This snap-on cable entry plate is a combination of the KDP/N and KDL/E systems
- The frame is partially open at the top and can be equipped with 2 KDT/ZE bushings
- Very good strain relief
- Ideal in cases where, in addition to wires without plug connectors, several wires with plugs need to be introduced into the distribution cabinet
- Two bushings accommodate up to eight pre-terminated cables
- Approval: CSA
- Protection class: IP 54
- Temperature resistance: -30 °C to +70 °C
- Material: Body: Polyamide / Seal: TPU/NBR/EPDM
- RoHS compliant
- UV resistant
- Made in Germany
- Fits standard 24-pin industrial connector openings
- Mounting is possible using locking hooks (sheet steel thickness: 1.5 mm - 2.0 mm) or M5 screws
- Locking hooks for sheet steel thicknesses of 1.5 mm to 2.0 mm are included in the delivery; locking hooks for sheet steel thicknesses up to 4.1 mm can be supplied
