Cable entry panel type KDL/D FDA

2- or 3-component frame

  • Easy installation
  • Use in food and pharmaceutical sectors
  • Protection class: IP 65 (with corresponding bushings and wires)
  • Temperature resistance: -40°C – +80°C
  • Material: Frame: PP / Block: TPE
  • RoHS compliant
  • Made in Germany
  • Suitable for standard 24- and 16-pole industrial connector cutouts and special size (single row)
  • Suitable cable entry bushing: KDT/X-FDA



SKU: 210843 Category:

Description

Options

Name GTIN Article
KDL/D 24/12-FDA, ws/bl, Set: White/blue 4045005301055 87142710
KDL/D 24/4-FDA Set: White/Blue 4045005372505 87142714
KDL/D 24/3-FDA Set: White/Blue 4045005425485 87142713
KDL/D 16/8-FDA Set: White/Blue 4045005285904 87142726
KDL/D 16/3-FDA Set: White/Blue 4045005176431 87142734
KDL/D 16/2-FDA Set: White/Blue 4045005340948 87142733
KDL/D 1/6-FDA Set: White/Blue 4045005370044 87142748



For standard hole size 24

Type of product Color GTIN Quantity Min. order
KDL/D 24/12-FDA, ws/bl, Set White / blue 4045005301055 1 1
KDL/D 24/4-FDA Set White / blue 4045005372505 1 1
KDL/D 24/3-FDA Set White / blue 4045005425485 1 1



For standard 16" hole

Type of product Color GTIN Quantity Min. order
KDL/D 16/8-FDA Set White / blue 4045005285904 1 1
KDL/D 16/3-FDA Set White / blue 4045005176431 1 1
KDL/D 16/2-FDA Set White / blue 4045005340948 1 1



Special size

Type of product Color GTIN Quantity Min. order
KDL/D 1/6-FDA Set White / blue 4045005370044 1 1

Additional details

Type of product Order number Color For Ø mm Number of Inputs Small / Medium / Large To enter Small / Medium / Large number of inputs Material Hole Qty. pcs. Overall dimensions
For standard hole size 24

KDL/D 24/12-FDA, ws/bl, Set

87142710

White / blue

2–12

12/0/0

Yes

/

No

/

No

12

Modified polypropylene

24-pole

1

KDL/D 24/4-FDA Set

87142714

White / blue

12–22

0/4/0

No

/

Yes

/

No

4

Modified polypropylene

24-pole

1

KDL/D 24/3-FDA Set

87142713

White / blue

12:30

0/1/2

No

/

Yes

/

Yes

3

Modified polypropylene

24-pole

1
For standard 16" hole

KDL/D 16/8-FDA Set

87142726

White / blue

2–12

8/0/0

Yes

/

No

/

No

8

Modified polypropylene

16-pole

1

KDL/D 16/3-FDA Set

87142734

White / blue

12–22

0/3/0

No

/

Yes

/

No

3

Modified polypropylene

16-pole

1

KDL/D 16/2-FDA Set

87142733

White / blue

22–30

0/0/2

No

/

No

/

Yes

2

Modified polypropylene

16-pole

1
Special size

KDL/D 1/6-FDA Set

87142748

White / blue

2–12

6/0/0

Yes

/

No

/

No

6

Modified polypropylene

—

1
