Automatic single-point lubricators with electromechanical drive and wire connection: SKF SYSTEM 24 - TLSD 1-DK series

SKF SYSTEM 24

Lubrication of intermittent equipment

The single-point lubricator with a wired connection is based on the proven TLSD automatic single-point lubricator. The main differences are the direct power supply from the equipment control panel and the presence of a wired signal transmission channel to the equipment's PLC.

Automatic lubricators with a wired connection deliver the required volume of lubricant at a specified frequency during equipment operation. With an external power supply, the lubricator can be turned on and off as needed. This allows for more precise lubricant delivery compared to traditional manual relubrication methods. The lubricator's output signals are fed to the PLC of the lubricated equipment and can be stored in memory.

Automatic single-point lubricator with wired connection is designed for lubrication of periodic equipment.

Features and Benefits

  • Lubrication is performed only during equipment operation.
  • Control and monitoring by connecting to PLC equipment
  • On-site and remote installation options available
  • Direct connection to power source
  • Lubricant consumption does not depend on temperature
  • Maximum discharge pressure: 5 bar
  • (75 psi) throughout the entire lubricant delivery period
  • Possibility of adjusting the lubricant consumption
  • Red, yellow and green LED indicators show the operating status of the lubricator
  • Reduced maintenance needs
  • The cartridges are filled with SKF greases specially developed for bearing assemblies.
  • Transparent cartridge for visual level control

Application areas

  • Critical equipment requiring high reliability and additional monitoring
  • Industrial equipment
  • Elevators
  • Compressors

Accessories

  • SKF DialSet software helps calculate optimal lubricant consumption
  • Wide range of additional accessories
Categories: ,

Description

Product Information
A. Drive - TLSD 1-DK
The TLSD lubricator top with a motorized drive and time setting switch. Comes with a cable, plastic cover, and a support plate for grease lubrication (TLSD 1-SP)		 Автоматический одноточечный лубрикатор SKF SYSTEM 24 серии TLSD 1- DK с проводным подключением
B. Cartridge - for example, LGWA 2/SD250
Replacement cartridge filled with SKF plastic grease or oil, volume 125 or 250 ml.
C. Support panel
The support plate for grease lubrication is supplied with the TLSD 1-DK lubricator.
The oil lubrication support plate (with integrated check valve) TLSD 1-SPV can be ordered separately.
Ordering Information - Components
Designation Description
TLSD 1-DK Wired lubrication system drive complete with support panel
TLSD K125/WA2 Wired drive complete with support panel and filled LGWA 2 125ml cartridge, no batteries required
TLSD K250/WA2 Wired drive complete with support panel and filled 250ml LGWA 2 cartridge, no batteries required
LGWA 2/SD125/K TLSD cartridge with LGWA 2 plastic grease, 125 ml, without battery
LGWA 2/SD250/K TLSD cartridge with LGWA 2 plastic grease, 250 ml, without battery
TLSD 1-SPV Support panel with built-in check valve
Cartridges
Plastic lubricant
 Description A set of 125 ml cartridges A set of 250 ml cartridges
LGWA 2 Multipurpose anti-seize lubricant LGWA 2/SD125/K LGWA 2/SD250/K
LGWA 2/SD125 1) LGWA 2/SD250 1)
LGEM 2 High loads, slow rotation LGEM 2/SD125 LGEM 2/SD250
LGHB 2 High temperature, loads, plain bearings LGHB 2/SD125 LGHB 2/SD250
LGHQ 2 High temperature with improved characteristics LGHQ 2/SD125 LGHQ 2/SD250
LGFG 2 Food industry, multipurpose LGFG 2/SD125 LGFG 2/SD250
LGFQ 2 Food industry, high loads, wide temperature range LGFQ 2/SD125 LGFQ 2/SD250
Chain oil
LHMT 68 Medium temperature oil LHMT 68/SD125 2) LHMT 68/SD250 2)
LFFM 100 Food grade oil, NSF H1 approved LFFM 100/SD125 2) LFFM 100/SD250 2)
1) It is recommended to use the LGWA 2/SD125/K and LGWA 2/SD250/K versions; they are supplied without batteries.
2) The support panel with check valve (TLSD 1-SPV) can be ordered separately.

Одноточечные автоматические лубрикаторы TLSD 125 и 250 мл

Technical specifications
Product Automatic lubricator series TLSD 1-DK with wired connection
Container with lubricant ../SD 125 125 ml (4.2 US fl oz)
../SD 250 250 ml (8.5 US fl oz)
Emptying time User configurable: 1, 2, 3, 4, 6, 8, 9, 10 and 12 months
Minimum supply of plastic lubricant ../SD 125 0.3 ml (0.01 US fl oz) per day
../SD 250 0.7 ml (0.02 US fl oz) per day
Maximum supply of plastic lubricant ../SD 125 4.1 ml (0.13 US fl oz) per day
../SD 250 8.3 ml (0.28 US fl oz) per day
Ambient temperature range from −20 to +50 °C (from −4 to +122 °F)
Maximum working pressure 5 bar (75 psi)
Drive mechanism Electromechanical
Connecting thread G 1/4
Maximum length of lubricant supply pipeline: plastic lubricant Up to 3 meters (10 feet) 1)
oil Up to 5 meters (16 feet)
LED status indicators Green (every 3 sec) Normal operation
Yellow (every 1 sec) Warning: High back pressure
Yellow (every 3 sec) Warning: Cartridge is almost empty (3 % remaining)
Red (every 1 sec) Anxiety, high back pressure
Red (every 3 sec) Alarm, empty cartridge
Red (every 5 sec) Alarm, lubricator error
IP protection class IP 41
Total weight (including packaging) TLSD 1-DK drive 355 g (12.5 oz)
Power supply 7–35 V / current up to 1.5 A
Cable length 550 mm (21.7 in)
Cable diameter max 4.8 mm (0.2 in)
Wire cross-section 24 AWG 7/32 (0.25 mm2)
Wire color White/brown + Positive (VCC) / - Negative (GND)
Green/Yellow Relay Contact 1 (N.O.) / Relay Contact 2 (N.O.)
1) The maximum pipeline length depends on the ambient temperature, the type of plastic lubricant and the back pressure created by the equipment.
